• Thread diameter: 5.0 mm
• Head diameter: 9.7 mm
• Drive: T20
• Countersunk head: For screwing panels to beams whenever flush countersinking of the head is required.
• Fully threaded: Screw fastening of fittings with through holes, absorption of high tensile forces, high contact pressure
• Galvanized zinc (WIROX®): For indoor and outdoor applications without direct weathering, 20 times higher corrosion protection than standard zinc plating, but not a substitute for stainless steel
• Hardened, with a sliding coating
• Multi-head, mills in wood – brakes on metal
• 4CUT tip: No pre-drilling required (depending on the wood), effectively reduces splitting. The square shank displaces the wood fibers and reduces the screw-in torque.
• 4CUT milling cutters from 160 mm
• T-Star plus: Clean bit fit and better guidance, e.g. when working overhead.
*Different design: Thread does not extend all the way to the head
| Length Ls [mm] | 30 |
|---|---|
| Brand | SPAX® |
| Length [mm] | 30 |
| Manufacturer part number | 4003530169892 |
| Unit price | CHF/unit price |
| Screw head | Countersunk head |
| Thread length LgV [mm] | 17 |
| Packaging unit | 500 |
| Thread length [mm] | 17 |
| EAN | 4003530169892 |
