3-way diverter valve Rotodivert EMV 110 F3L, DN15 (1/2") with actuator

• Compact drive motor with a 3-way brass diverter valve. For installation in closed heating systems, such as from central heating to domestic hot water or from oil/gas boiler to solid fuel boiler.
• With relays for 2-point control and for parallel operation of multiple drives
• External connection via the connection cable (1 m long)
• Limit switch signal in position BAB (e.g. for pump control)
• Manual hand adjustment
• Anti-lock braking function: in the event of a blockage, the engine changes its direction of rotation in an attempt to release the blockage.

Technical data:

drive

• Nominal voltage: 230 V, 50 Hz / IP44
• Power consumption: 9 W in operation, 5 W in standby mode
• Limit switch: 1(1) A, 250 V / 50 Hz
• Setting time for 90°: 18 s
• Connection cable: 1 m (4x 0.5 mm²)
• Torque: max. 8 Nm
• Ambient temperature: 0° to 55°C non-condensing

Diverter valve

• Material: Brass
• Seals: O-rings, VITON, EPDM
• Maximum operating pressure: 10 bar
• Differential pressure: max. 1 bar
• Angle of rotation: 90°
• Operating temperature: 2 °C to 110 °C
• Leakage rate: approx. 0.2% of Kvs
• Medium: Heating water or water mixture (glycol max. 50%, for frost and corrosion protection)
