- Installation vertically or horizontally.
- For use as a return temperature boost in mixing mode or as a distribution in the buffer supply (70°C or 80°C)
- For optimal condensation protection, installation of the valve in the boiler return line is recommended.
Technical data:
- DN 20 (3/4") IG
- For solid fuel boilers up to 32 kW
- Flow rate: KVS 3.5
- Maximum operating pressure: 10 bar
- Maximum operating temperature: 100°C
- Material: Brass
| Unit price | CHF/piece |
|---|---|
| Target temperature | 45°C |
