Solid fuel loading set Easyflow Wood-Konstant DN25, 20-80°C with pump Grundfos UPM3S AUTO 25-60

• For maintaining high return flow rates in solid fuel boiler systems
• Adjustable from 20°C to 80°C

Lead time:

• 1x Flow pump flange ball valve with thermometer handwheel (thermometer ring red, 0-120°C) and adjustable gravity brake by turning the handwheel 45°

1 x spacer

1x screw connection

• 1x T-piece for mixer

1x pump

Return:

• 1x Return pump flange ball valve with thermometer handwheel (thermometer ring blue, 0-120°C)

2x union nut and seal

1x screw connection

1x three-way mixing valve with ACC30 fixed value actuator

Technical data:

• Power output: up to 50 kW
• Flow rate: up to 2150 l/h
• Maximum operating temperature: 110 °C
• Maximum operating pressure: 10 bar
• Connections: DN25(1") internal thread
• Gravity brake: 20 mbar
• Axle dimension: 125 mm
• Material: Brass
• Insulation: EPP
• Dimensions (with insulation) HxWxD: 380x250x210 mm
• KVS value 6.0
