• Corrosion-resistant double harp absorber made of solid copper
• Long-lasting, highly selective coating for light-to-heat conversion
• Silicone-free disc seal
• Two-pipe connection technology with forced flow
• Heat-resistant mineral wool insulation
• Seawater-resistant aluminum frame
• Eligible for government funding
• Up to 7 collectors can be connected in series
• Simplified assembly thanks to cutting ring screw connection
Technical data:
• Efficiency: 79.3%
• Operating pressure: max. 6 bar
• Test pressure: 9 bar
• Solar glass: 4 mm prismatic
• Housing color: Black, powder-coated (RAL 9005)
• Connection: 2 x ø 22 mm copper
Collector Identification:
• Manufacturer: SUNEX SA
• Type: SX series
• Reg. No.: 011-7S140 F
(Collector connection and mounting kit not included)
| Manufacturer part number | 130101125 |
|---|---|
| Design | vertical |
| Dimensions L x W x H [mm] | 2240 x 1120 x 100 |
| Unit price | CHF/piece |
| Weight [kg] | 45 |
| Gross/net area [m²] | 2.51 / 2.31 |
| Type | SX 2.51 |
