• For legally compliant billing of consumption and heating costs in accordance with the Heating Costs Ordinance (HeizkV)
• With integrated radio module (Wireless M-Bus, OMS, 868 MHz)
• Each meter comes with an individual AES radio key.
• Detachable calculator with integrated wall mount
• Integrated optical interface
• Replaceable battery
• Installation position: horizontal or vertical
• Can be used in return and forward flow
• MID compliant (MID DE-16-MI004-PTB025)
• 230 V/AC power supply can be retrofitted on site
Technical data:
• Ambient temperature: 5-55°C
• Maximum operating pressure: 16 bar
• Operating temperature range: 15-90°C
• Housing material: Brass
• Sensor cable length: 1.5 m
• Protection class: IP65
• Power supply: 3V battery (A-cell) 10 years
• Measurement accuracy: Class 2 Class 3
• Measurement cycle: 2 and 60 sec.
• Sensor: ø 5.2 mm
• Cable length of the calculator unit: 0.85 m
| Installation length [mm] | 110 |
|---|---|
| Brand | Elster |
| Nominal size [mm] | DN 15 |
| Flow rate [m³/h] | 0.6 |
| Unit price | CHF/piece |
| Thread | DN 20 (3/4") |
