- For installations in the heating and industrial sectors
- Operating pressure: DN 8 (1/4") DN 25 (1") max. 20 bar, DN 32 (1 1/4") DN 50 (2") max. 16 bar, DN 65 (2 1/2") DN 80 (3") max. 10 bar
- Temperature range: 10 to +80°C (depending on operating pressure)
- Body: Nickel-plated brass
- Ball: Chrome-plated brass
- With lever handle
| Surface protection | nickel-plated |
|---|---|
| Length [mm] | 66 |
| Connection 1 | Internal thread |
| Connection 2 | Internal thread |
| Unit price | CHF/piece |
| Complete passage | true |
| Housing material | Brass |
| Size | DN 25 (1”) |
| Length [mm] | 66 |
| Design | Lever handle |
| Max. medium temperature (continuous operation) [°C] | 80 |
| PN [bar] | 20 |
| Operation | Handle |
| Material grade | CW617N |
| Max. working pressure [bar] | 20 |
