- With fresh water station FWS280 (80 kW)
- Optimized for heat pumps
- Lower flow temperature sufficient
- Connection for 2 mixing circuit groups for high and low temperature circuits
- Removable thermal insulation
|
Type
|
BSPW
|
1000
|
SL 1000
|
1000B
|
| Energy efficiency class |
A+ to F
|
C | C |
C
|
|
|
1
|
2 |
0
|
|
Memory content
|
[l]
|
915
|
900
|
915
|
|
Solar heat exchanger surface below
|
[m²]
|
3,0
|
3,0
|
|
|
Heat exchanger surface solar top
|
[m²]
|
|
1.9
|
|
|
Heat exchanger content solar bottom
|
[l]
|
19.8
|
19.8
|
|
|
Heat exchanger content solar top
|
[l]
|
|
11,0
|
|
|
[Ltr./min.]
|
25
|
25
|
25
|
|
Diameter with thermal insulation
|
[mm]
|
1000
|
1000
|
1000
|
|
Diameter without thermal insulation
|
[mm]
|
790
|
790
|
790
|
|
Total height with thermal insulation
|
[mm]
|
2110
|
2110
|
2110
|
|
Total height without thermal insulation
|
[mm]
|
2040
|
2040
|
2040
|
|
Tipping dimension without thermal insulation
|
[mm]
|
2068
|
2068
|
2068
|
|
Weight of fresh water station
|
[kg]
|
20
|
20
|
20
|
|
Ref.No
|
|
8615348
|
8615349
|
8615713
|
- Hot water output at 50°C buffer/hot water temp. 45°C [Ltr./min.]: 25
| Contents [l] | - |
|---|---|
| Overall height [mm] | 2110 |
| Brand | WOLF |
| lower WT [m²] | - |
| Manufacturer part number | 8615713 |
| Tilting dimension [mm] | 2068 |
| Unit price | CHF/piece |
| Diameter without insulation [mm] | 790 |
| Diameter with insulation [mm] | 1000 |
| Ref. No. | 8615713 |
| Weight [kg] | 194 |
| upper WT [m²] | - |
| Type | BSP-W 1000B |
| Energy Efficiency Class | C |
| EAN | 4045013385153 |
