- Protection rating: IP54
- Cable: 3 m, H07RNF 3G 1.5 mm², black
- With PRCDK+ residual current device: 16 A 250 V / AC, I∆N = 30 mA
- Case color: grey / black / red
- Mains side: 1.5 m cable, safety plug (black/green)
- Output side: 1.5 m cable, protective contact coupling with hinged cover (black/green)
- The PRCDK+ detects and protects in the following error cases:
- Interruption of L or N conductor
- Undervoltage or power outage
- Overvoltage
- DC voltage
- Wiring error
- Rated residual current ≥ 30 mA
- Mobile personal protection against electrical accidents on construction and assembly sites for IT networks
- The PRCDK+ is an all-pole switching portable residual current device with electronic fault evaluation for use between each socket of the power generator and the load, preferably directly behind each socket.
- The PRCDK+ (unlike the PRCDS+) does not have protective conductor monitoring, as it was designed exclusively for use in IT power networks (isolating transformers, power generators, generators).
- Personal protection switch according to DIN VDE 0661
- DGUV Information 203006 (formerly BGI/GUVI 608)
- Device fully assembled and tested
| Manufacturer part number | 4680001 |
|---|---|
| Unit price | CHF/piece |
| Ref. No. | 4680001 |
| EAN | 9003399502989 |
