• HP type tube collectors
• Pump station fully assembled with:
- 1 x pump, Wilo Para ST 25/6 PWM
- 1 x flow meter 2 to 12 ltr./min.
- 1 x temperature display in the flow and return lines
- 1 x ball valve with gravity brake, adjustable, in the flow and return lines
- 1 x KFE drain valve in the return line
- 1 x pressure gauge 10 bar
- 1 x diaphragm safety valve 6 bar
• 1 x connector set with cross T-piece, elbow, KL screw connection for Cu pipe ø22 mm and 2 x connection hose 1 m for roof entry
• 1 x wall bracket and corrugated hose set for expansion vessel (incl. shut-off valve)
• 1 x DeltaSol CS Plus solar controller incl. 4 sensors
• Stainless steel roof mounting kit, suitable for mounting on almost any type of tile, for example, Frankfurt tile
• Collector Identification:
Manufacturer: SUNEX SA
Type: HP series (HP 22, HP 30)
Reg. No.: 011-7S2651 R
• Suitable for approximately 4 to 5 people
• 2 x tube collector type HP 22 (3.61 m²)
• 1 x expansion vessel 25 l
• 1 x 20 kg solar fluid (ready-mixed)
Memory EV-TWS-2W 300 (97 011 92)
• Diameter with permanently foamed insulation: 660 mm
• Overall height: 1726 mm
• Tilting dimension: 1845 mm
• Energy Efficiency Class: A
The components of the solar packages are based on a basic solar system configuration. Depending on the type of house, location, and number of occupants, they must be reviewed by a professional and supplemented or adjusted as necessary.
| Manufacturer part number | |
|---|---|
| Version | without memory |
| Unit price | CHF/set |
