• Install vertically, installation direction from bottom to top, from AG to union nut
• Responds to a flow rate of approximately 0.8 l/min or higher.
• Suitable for flow rates up to 70 l/min
• Switch NOT suitable for “direct switching” of the pump
Technical data:
• Operating voltage: 30 V / DC
• Contact type: Normally open contact as signal transmitter for standard control inputs up to 30 V, reed contact with triac
• Switching capacity: 10 mA
• Material: Brass CW 617N
• Connection: DN 25 (1") male thread x DN 25 (1") female thread
• Cable length: 1.5 m
• Temperature range: -20 to +90°C
| Manufacturer part number | DFS2021 |
|---|---|
| Unit price | CHF/piece |
