- Suitable for installations in the heating, drinking water and industrial sectors.
- Operating pressure: DN 10 (3/8") DN 20 (3/4") max. 42 bar
- DN 25 (1”) DN 50 (2”) max. 35 bar
- Temperature range: 5 to +120°C
- Body: Chrome-plated brass
- Ball: Chrome-plated brass
- Seal: Teflon (PTFE)
- Passage: reduced
- For DVGW approval, ball valves are tested with an operating pressure of 10 bar.
- This is a regulation of the DVGW, worksheet W5701 and DIN EN 13828.
Our ball valves comply with the current ISO 7 standard. Naturally, the maximum pressure ratings specified in the technical data apply.
- With wing handle
- Loose union nut
- Sealing possible
| Brand | Giacomini |
|---|---|
| Length [mm] | 70 |
| IG | DN 15 (1/2") |
| Manufacturer part number | R251WX073 |
| Unit price | CHF/piece |
| Union nut | DN 20 (3/4") |
