Delta B-VU2 oil burner pump

Universal oil burner pumps with variable direction of rotation

• Suitable for biogenic fuels or additives in heating oil

Direction of rotation: clockwise and counterclockwise (reversible) !!!

Technical data for type VU and BVU

• Viscosity range: 1.2 – 12 mm²/s
• Oil temperature: max. 60 °C
• Pressure range: 6 – 18 bar
• Suction-side vacuum: max. 0.5 bar
• Suction-side pressure: max. 2 bar
• Maximum speed: 3,500 rpm
• Coil: 230 V, 50/60 Hz
• Dimensions (EN 225): Hub ø 32, Shaft ø 8
• Connections flow and return: DN 8 (1/4")
• Nozzle connection: DN 6 (1/8") on both sides
• Pressure/vacuum measuring connections: DN 6 (1/8")
• Operating system: Single-strand or dual-strand
• Connection cable (700 mm)

Direction of rotation

• Simple direction change for clockwise and counterclockwise rotation
• Reversing the direction of rotation without opening the lid, using only a screwdriver.
• 4 pumps in one model
• Installation possible on almost any oil burner
