• Water meters for legally compliant billing of consumption in accordance with the Heating Costs Ordinance (HeizkV)
• With integrated radio module (Wireless M-Bus, OMS, 868 MHz)
• Individual AES radio key included with each meter; integrated optical interface
• Impeller scanning, inductive scanning
• Unit in m³/h
• Readable via display and radio for 15 months
• 15 monthly and semi-monthly values readable via optical interface
• Digital display
• Display rotatable by 360°
• Designed battery life of 10 years
• Leak detection
• Installation position: horizontal and vertical
• Includes calibration and conformity assessment fees
Technical data:
• Mechanical class: M1
• Electromagnetic class: E1
• Maximum operating pressure: 10 bar
• Cold water temperature range: 0.1-30°C
• Hot water temperature range: 0-90°C
• Protection class: IP56
• Power supply: 3V battery (A-cell) 10 years
• Material: Brass
| Installation length [mm] | 80 |
|---|---|
| Brand | Brummerhoop |
| Connection | DN 20 (3/4") |
| Unit price | CHF/piece |
| Nominal diameter | DN 15 |
| Flow rate [m³/h] | Q3 = 2.5 (Qn = 1.5) |
