- Heating water flow rate: up to 5.3 m³/h
- Power output at ∆t=20°C up to 120 kW
- The pre-chamber is located inside the return chamber.
- Boiler connections DN40 (1 1/2") female thread socket, flow connection on the side, return connection at the bottom.
- Group connections: DN32 (1 1/4") female thread socket
- Drainage sockets DN15 (1/2") female thread for flow and return chambers
- Insulation (35 mm) with galvanized steel sheet casing (0.6 mm)
- Compact design with integrated flow and return
- Group departures lying next to each other
- pressure tested and galvanized
- Operating pressure: max. 6 bar
- Flow temperature: max. 90°C
- Pressed-in flow and return markings in the sheet steel casing
| Number of heating groups | 2 |
|---|---|
| L [mm] | 770 |
| Unit price | CHF/piece |
| Type | HVM SU-2 |
