• Galvanized steel
• The screw is screwed directly into the drilled hole without a dowel.
• Approved for use with masonry bricks, solid calcium silicate bricks, perforated calcium silicate bricks and lightweight concrete, except for thread diameters of 16.0 and 20.0 mm.
• With ETA 15/0784 approval
• Screw diameters 10.0 + 12.0 + 16.0 + 20.0 mm are reusable, however, they must first be tested using the test sleeve (94 008 05-...08).
• Thread diameter: 6.0 mm
• Drill diameter: 5.0 mm
• Wrench size: 8
• Disc diameter: 11.0 mm
• Hex head: Offers very high power transmission when screwing
• Fully threaded: Screw connection possible without dowels, withstands high tensile forces, high contact pressure
• Galvanized: Blue passivated. For indoor and outdoor applications without direct weathering, but not a substitute for stainless steel.
| Brand | Heco |
|---|---|
| Length [mm] | 40 |
| Unit price | CHF/unit price |
| Clamping thickness [mm] | 5 |
| Screw head | Hexagon head |
| Packaging unit | 100 |
