Stainless steel underfloor heating manifold type Dynacon with 2 heating circuits

The required flow rate of each heating circuit is set directly at the valve in l/h.

• Thanks to the integrated flow regulator in each heating circuit, the flow rate is never exceeded, even if neighboring heating circuits close.

• Primary side: 2 free-rotating nuts with DN 25 (1") female thread, flat sealing
• Distributor: 2 x manual air vents DN 15 (1/2"), 2 x fill and drain valves DN 20 (3/4") hose connection
• Outlet: DN 20 (3/4") male thread with Eurocone
• Distance between outlets: 50 mm
• Wall brackets with sound insulation including mounting hardware
• Fully pre-assembled, without connection fittings

Technical data:

• Material: Flow and return manifolds made of stainless steel (VA)
• Maximum operating pressure: 10 bar
• Operating temperature: 2°C – 70°C
• Valves: M30x 1.5 (Heimeier compatible in the return manifold)
• Flow rate per heating circuit: 30 – 300 l/h
