• For use in closed circuits with low, undefined pressure, e.g., heating systems
• Closed when not powered (open on request)
• The valves do not require differential pressure
• Installation position: only with the magnet in a standing position
• Media temperature: -10°C to +80°C
• With magnetic coil and device plug
• Voltage: 230 volts, 50 Hz
• Protection rating: IP65
• 100% ED-VDE0580
• Quick-closing
• Made in Germany
• Valve closed in rest position (NC). When energized, the solenoid coil first opens the pilot port and then, either directly or assisted by a pressure differential, lifts the diaphragm from the valve seat. The valve closes by spring force.
• Permissible pressure: 0 - 12 bar
• Seal: Viton (FKM)
• Body: Brass
• Oil-resistant membrane
• Media: Oil, air, water
| Brand | GSR® |
|---|---|
| L x H [mm] | 67 x 122 |
| Manufacturer part number | G043.004606.090.009.090 |
| Unit price | CHF/piece |
| kv value [m³/h] | 3.6 |
| Voltage [V/Hz] | 230 / 50 |
| Size | DN 10 (3/8") |
| Nominal diameter DN | 10 |
| Permissible pressure (bar) | 0 – 12 |
| Connection R inside | DN 10 (3/8”) |
| Type | D4322 1002 012 |
