Heimeier Multilux Eclipse twin-pipe operation, internal thread, corner

• For installation in two-pipe heating systems on radiators with a lower two-point connection, such as bathroom, designer, universal or valve radiators.

• Automatic hydraulic balancing via integrated flow regulator ensures that the flow rate in the radiator is never exceeded, even when neighboring valves close.
• The required flow rate for each radiator is set directly on the thermostatic valve body.
• The flow rate can be continuously adjusted within the flow rate range using the adjustment key, setting 115
• The thermostat head and shut-off head can be interchanged, making it suitable for mounting on the left or right side of the radiator.
• Flow rate range from 10 to 150 l/h
• Connection ThKopf: M30x1.5
• Center-to-center distance: 50 mm

Technical data:

• Valve material: Red brass, corrosion-resistant
• Spindle material: Stainless steel spindle with double O-ring seal
• Material O-ring: EPDM
• Maximum operating pressure: 10 bar
• Maximum operating temperature: 120 °C
• Maximum operating temperature with casing: 90°C
• Minimum operating temperature: 10°C
• Maximum differential pressure: 60 kPa
• Minimum differential pressure:
• 10100 l/h = 10 kPa
• 100150 l/h = 10 kPa

• Nickel-plated red brass
