Digital fuel level indicator GOK type Smartbox 3 incl. probe

• Display device for dry and protected rooms
• 1 relay with normally open and normally closed contacts, maximum 250 V AC, 3.5 A
• Protection class: IP 30

• For local content measurement of unpressurized oil tanks
• Display up to 200 m from the tank

Technical data:

• Operating voltage: 230 V/AC, 50 Hz
• Measuring range for heating oil: up to 2.90 m tank height
• Water measuring range: up to 2.50 m tank height
• Tank connection: DN 25 (1"), DN 40 (1 1/2"), DN 50 (2")
• Probe cable: extendable to 200 m
• Measurement accuracy: 1%

• Scope of delivery:
• Display unit with LCD display
• Level probe 6 m
• Mounting accessories
