Umwälzpumpe Evenes HE-HS 55-25, DN25(1"), PN10 230V, Baulänge: 130mm

For use in heating, air conditioning and industrial plants
Flexible application range through the following options:
• 4 proportional characteristic curves
• 3 constant characteristic curves
• Power consumption display in watts
• Switchable night setback
• EC permanent magnet rotor
• Stall-proof motor
• Adjusting the pump output to the actual needs of the system
• Simple electrical connection via plug connector
• Includes thermal insulation shell

Technical data: EVENES HE-HS 35 –XX 55-XX
• Maximum delivery head: 4.0 m 6.0 m
• Maximum flow rate: 2600 l/h 3200 l/h
• Operating voltage: 1 x 230 V / 50 Hz
• Motor protection: no external motor protection required
• Protection class: IP 42
• Heat class: F
• Ambient temperature: 0°C to +40°C
• Medium temperature range: +5°C to +110°C
• Maximum operating pressure: 10 bar
• Pump housing material: Grey cast iron, KTL-coated
• Approved funding media:
Heating water according to VDI 2035 water/glycol mixtures 1:1
