For use in heating, air conditioning, cooling and industrial systems
• Bluetooth interface for wireless data exchange
• The display shows the current flow rate in m³/h, power consumption [W] and the cumulative energy consumption [kWh].
• Automatic venting function
• Automatic unblocking function
• Dynamic Adapt plus
• Proportional pressure control
• Constant pressure control
• Multi-Flow Adaptation
• Reset function
• Key lock
• Q-Limit max. to limit the maximum volume flow
• Q-Limit min. to limit the minimum volume flow
• No-Flow Stop (zero-flow shutdown)
• Automatic night setback
• Worst-point control (Δp-c control with external actual value sensor)
• Variable slope of the Δp-v characteristic curve
• Includes thermal insulation shell
Technical data:
• Operating voltage: 230V/50-60Hz
• Media temperature: -10°C - 110°C
• Ambient temperature: -10°C - 40°C
• Protection rating: IPX4D
• Housing material: Cast iron
Compatible with Wilo-Smart Balance App
The Wilo Smart Balance app allows for easy hydraulic balancing. The complete report can be exported as a PDF document for submission to the Federal Office for Economic Affairs and Export Control (BAFA) for billing purposes.
| Installation length [mm] | 360 |
|---|---|
| Brand | Wilo |
| Manufacturer part number | 2186221 |
| Nominal pressure | 10 |
| Unit price | CHF/piece |
| Nominal size | DN 100 |
| EEI ≤ | 0.17 |
| Type | 100/0.5-12 |
| EAN | 4048482782201 |
